SP32XP 32-POWER AUTOMATIC LEVEL
- Magnetically dampened, automatic compensator for optimum range and accuracy
- 32-power magnification
- Crisp, clear optics that allow for brighter, sharper images-especially in low light conditions
- Horizontal and vertical cross hairs with 1:100 stadia lines - measures level, alignment & estimates distance
- Fine motion horizontal tangent knobs on left and right sides allow friction braked rotation, endless horizontal drive and precise pointing and angle measurement
- Solid leveling metal base with three precision leveling screws provides stability in all weather and jobsite conditions
- 360° Graduated horizontal circle in 1-degree increments for layout applications
- 8 ’ / 2 mm circular bubble vial with 90-degree mirror for quick and accurate set-up
Specifications
- Magnification
- Leveling Accuracy
- Angular Accuracy
- Working Range
- Field of View
- Minimum Focus
- Compensator range
- Comp Setting
PAL32 Automatic Level
- 32X
- Up to 1/16-in at 150-ft (1.5mm @ 45m)
- 1°
- Up to 400-ft (92m)
- 1° 30’ or 2.6ft@100ft
- 1.64 feet
- +/-15’
- ±0.3”
Contents
- Level, Lens Cover, Plumb Bob, Adjustment Tools, Carrying Case, User Manual
